PS16L

Electric walker stacker 1600 kg

PS16L

Electric walker stacker 1600 kg

PSL series are tailored to suit most walkie stacker operations. These stackers are of premium quality.

more information

	Designation
	PS16L29FFLLP Electric walker stacker 2900 mm free lift 1600 kg Weight : 1215 kg Bar code : 3700664836164 Catalogue P.102
	PS16L32FFLLP Electric walker stacker 3200 mm free lift 1600 kg Weight : 1230 kg Bar code : 3700664836140 Catalogue P.102
	PS16L36FFLLP Electric walker stacker 3600 mmfree lift 1600 kg Weight : 1245 kg Bar code : 3700664836133 Catalogue P.102
	PS16L40FFLLP Electric walker stacker DUPLEX 4000 mm free lift 1600 kg Weight : 1295 kg Bar code : 3700664836119 Catalogue P.102
	PS16L40FFLLPDX Electric walker stacker TRIPLEX 4000 mm free lift 1600 kg Weight : 1295 kg Bar code : 3700664804354 Catalogue P.102
	PS16L43FFLLP Electric walker stacker 4300 mm free lift 1600 kg Weight : 1325 kg Bar code : 3700664836096 Catalogue P.102
	PS16L46FFLLP Electric walker stacker 4600 mm free lift 1600 kg Weight : 1340 kg Bar code : 3700664836065 Catalogue P.102
	PS16L53FFLLP Electric walker stacker 5300 mm free lift 1600 kg Weight : 1370 kg Bar code : 3700664836058 Catalogue P.102
	PS16L55FFLLP Electric walker stacker 5500 mm free lift 1600 kg Weight : 1380 kg Bar code : 3700664803494 Catalogue P.102

DESCRIPTION

TECHNICAL CHARACTERISTICS

PSL series are tailored to suit most walkie stacker operations.
Available in 3 models: PS12L, PS16L and PS20L
You can compare all models, by checking the product page of each model and/or download technical documentation
PS16L load capacity: 1.6 metric tons
This stacker is available with a DUPLEX or TRIPLEX mast depending on the required height.
The long steering handle guarantees the operator is at a safe distance from the stacker and improves ergonomics. Also, its design ensures less operational efforts compared to short handle stackers.
Stacker operations are more reliable and faster thanks to the proportional lift system.
This heavy-duty electric walker stacker is ergonomic, compact and extremely maneuverable.
Equipped with a powerful, maintenance-free AC Schabmüller motor and core components from top leading brands.
The structure has four points of contact for best stability
CAN-BUS technology eases diagnosis and settings on maintenance operations. It eliminates the need for excessive wiring so that reliability is guaranteed. Also, parts last longer with digital signals than analog signals.
Robust and reliable design
The robust chassis and its 8mm thick mainframe protect the stacker and its components against impact collisions.
The stainless steel battery cover provides enhanced protection and reduces maintenance costs and possible damages.
AC motor design can withstand dirty work area floors as components and brakes are protected from impacts.
The controller is protected against dust and splash (IP54).
Powerful and maintenance free German Schabmuller AC traction motor along with Kordel drive unit, lntorqe brake and Wicke steering wheels are the perfect combination to provide the best performance, safety and flexibility under any circumstances. Besides, they also reduce operating costs. AC motor is always ready for action whether it is a light or strong acceleration.
The stacker and its components have been specially designed to perform maintenance and servicing with ease. With only 2 screws, the main cover can be easily removed for easy access all components. Wheels and rollers can be easily replaced without a lifting device.
The electronically controlled proportional lift and lower system ensures accurate fork positioning and stacking operations.
Proportional lift works best when dealing with high stacks.
Each PS L series has a battery corresponding to a specific type of use: PS16L has a 3 VBS-270 Ah battery for short stackers used in narrow operating areas.
Electric propulsion and pedestrian drive
Rated capacity: 1.6 metric ton
Load center distance: 600 mm
Load distance, center of drive axle to fork (x): 647 mm
Wheelbase: 1293 mm
Polyurethane wheels (PU)
Steering wheels dimensions: 230 x 70 mm
Front rollers dimensions: 85 x 75 mm
Stabilizing rollers dimensions: 150 x 54 mm
Number of front / rear wheels (x= steering wheel): 1 x + 1 / 4
Straddle legs center distance: 522 mm
Rear rollers center distance: 390 / 505 mm
Tiller height in drive position min. / max.: 850 / 1385 mm
Fork height lowered: 90 mm
Overall length: 1964 mm
Length without forks: 814 mm
Overall width: 820 mm
Fork dimensions s/e/l: 60/180/1150 mm
Width across forks: 570 / 685 mm
Ground clearance: 28 mm
Aisle width for pallets 1000 x 1200 crossways: 2406 mm
Aisle width for pallets 800 x 1200 lengthways: 2393 mm
Turning radius: 1510 mm
Travel speed laden / unladen: 5,7 / 6 km/h
Lift speed, laden / unladen: 0,13 / 0,2 m/s
Lowering speed, laden / unladen: 0,2 / 0,14 m/s
Gradeability performance of 6% laden and 12% unladen
Electromagnetic service brake
Battery weight: 245 to 255 kg depending on the model
Type of drive control: AC - speed control
Sound level at driver's ear acc. to EN 12053:<70 dB
Download the product specifications for further technical information
