PT20L-ION

Pedestrian-operated lithium electric pallet truck with 100 Ah battery 2000 kg

PT20L-ION

Pedestrian-operated lithium electric pallet truck with 100 Ah battery 2000 kg

Powerful, reliable 2000 kg lithium electric pallet truck. Fast-charging 100 Ah battery for handling heavy loads. Suitable for demanding environments and confined spaces. Guaranteed performance and safety.

more information

	Designation
	PT20L-ION Pedestrian-operated lithium electric pallet truck with 100 Ah battery 2000 kg Weight : 411 kg Bar code : 3700664813516

DESCRIPTION

TECHNICAL CHARACTERISTICS

The PT20L-ION electric pallet truck can carry loads of up to 2000 kg. This lithium pallet truck offers a reliable solution for demanding industrial environments. Equipped with a fast-charging 100 Ah lithium-ion battery, this model optimises work cycles thanks to rapid recharging and constant performance. Suitable for use in confined spaces, this lithium electric pallet truck is the ideal choice for warehouses, logistics centres and loading zones.

Benefits of the PT20L-ION lithium electric pallet truck
Large load capacity: With a capacity of 2000 kg, the PT20L-ION can handle heavy loads in complete safety, making it ideal for intensive handling tasks.
100 Ah lithium-ion battery: Lithium-ion technology offers shorter charging times and greater durability than conventional batteries, allowing longer use between recharges.
Compact, robust design: The 518 mm fork length makes the PT20L-ION easy to manoeuvre, even in confined spaces, while the 8 mm thick chassis ensures long-term durability.
Enhanced security: Secure PIN or RFID start-up prevents unauthorised use, while the electromagnetic brake ensures precise control when stopping.
Top-of-the-range components: Incorporates top-quality parts from leading brands, guaranteeing optimum reliability and performance.

Main technical specifications of the PT20L-ION lithium electric pallet truck
Load capacity: 2000 kg
Fork dimensions: 60 x 173 x 1150 mm
Overall length: 1668 mm
Overall width: 729 mm
Turning radius: 1482 mm, for easy manoeuvring in narrow aisles
Travel speed: Up to 6 km/h without load, 5.7 km/h with load
Polyurethane wheels: provide better traction and reduce floor wear
Electromagnetic braking: for safe, controlled stopping
AC traction motor: 1.3 kW, requiring little maintenance
Permissible gradient: 15% without load, 8% with load, for ramps and inclined platforms
Weight with batteries: 411 kg
Noise level: less than 70 dB for a pleasant working environment

Performance and field applications of the PT20L-ION lithium electric pallet truck

The PT20L-ION is indispensable in work environments where the handling of heavy loads is a daily requirement. Its ability to operate efficiently on gradients of up to 15% with no load makes it perfect for warehouses with ramps or high storage areas.

A turning radius of 1482 mm and the ability to work with the tiller straight at 90° mean it can make the most of tight spaces, such as loading bays or warehouses with high storage density.

With lifting and lowering speeds optimised to avoid jerking, the PT20L-ION ensures smooth, safe operations, even with heavy loads. This model is ideal for companies that need to handle large quantities of pallets or heavy goods quickly.

Maintenance and energy savings on the PT20L-ION lithium electric pallet truck

The PT20L-ION is designed to minimise maintenance costs thanks to its durable components and robust design. The maintenance-free AC motor and lithium-ion battery ensure low energy consumption of just 0.337 kWh/h, making it an economical and environmentally-friendly choice.

Recommended uses for the PT20L-ION lithium electric pallet truck
Logistics warehouses and distribution centres: Ideal for handling heavy loads and transporting pallets quickly.
Manufacturing industries: Suitable for moving finished products or raw materials over long distances.
Loading bays: The PT20L-ION's compact design maximises the space available for loading and unloading lorries.
Mass distribution shops: Facilitates the handling of large and heavy stocks in warehouses.

PT20L-ION lithium electric pallet truck operator safety and comfort

This model is equipped with a PIN or RFID code start-up system, limiting access to authorised operators. The polyurethane wheels ensure greater stability on smooth surfaces, while the low noise level reduces disturbance, guaranteeing a pleasant working environment.

Technology and innovation for the PT20L-ION lithium electric pallet truck

The PT20L-ION's lithium-ion battery offers faster charge cycles and greater energy efficiency, increasing the device's availability for continuous operations. The state-of-the-art design places this pallet truck in the premium category, offering exceptional performance for demanding users.

The PT20L-ION electric pallet truck is a powerful and flexible materials handling solution, perfect for industrial environments requiring high load capacities and great manoeuvrability.

Documentation

Data sheet
